... the other way.
- Compact design, low maintenance
- Machine frame made of stainless steel
- Polypropylen storage and working trough
-
-Variable frequency controlled cylinder drive
CONTROL TYPE S
-
-Simple control by push-button, manual or semi-automatic mode
-
-Possibility of upgrade to type SE
COMPACT S, SE
Special features:
-
-Spray bar for rinsing
-
-Spray bar for application of separation solution
-
-Spray bar for pickling
-
-Additional tank for separation solution / pickling
Basic machine as MODEL S with additional features:
DOUBLE WING DOOR
-
-Easy access for maintenance
-
-Protection of machine parts
AUTOMATIC COVER
-
-Reduces heat loss
-
-Protects from impurities
-
-Keeps electrolyte smog away from user
ECOPLATER DEGREASE, DECHROME, NICKEL
MODEL S
GALVACONTROL SE
-
-PLC electronics with interface to remote control
-
-Fully automatic process or manual operation
-
-Adjustable production parameters
Process time:
Degrease
Dechrome
Nickel
10 minutes
6 µm layer in 12-15 minutes
15 µm layer in 30 minutes with 5A / dm²
Temperatures:
Degrease
Nickel
40 °C ± 1,5 °C
40 °C ± 1,5 °C
Immersion:
50% of cylinder surface
